10
2. Attach other end of high pressure hose (C) to
high pressure outlet on pump. See Figure 7.
Tighten by hand.
3. Run water through your garden hose for
30 seconds to clean out any debris.
IMPORTANT: DO NOT siphon standing water
for the water supply. Use ONLY cold water (less
than 100°F (38°C)).
4. Before connecting garden hose to water inlet,
inspect inlet screen. See Figure 8. Clean
screen if it contains debris or have it replaced
if damaged. DO NOT run pressure washer if
inlet screen is damaged.
5. Connect the garden hose (not to exceed
50 feet (15 m) in length) to the water inlet.
Tighten by hand.
6. Turn ON the water, press red button on the
spray gun (D) and squeeze the trigger to
purge the pump system of air and impurities.
See Figure 9.
Checklist Before Starting Engine
Review the unit’s assembly to ensure you have
performed all of the following.
1. Be sure to read the Important Safety
Information and Operation Instruction
sections before using pressure washer.
2. Make sure handle is in place and secure.
3. Check that oil has been added to proper level
in the engine crankcase.
4. Add proper fuel to fuel tank.
5. Check for properly tightened
hose connections.
6. Check to make sure there are no kinks, cuts,
or damage to high pressure hose.
7. Provide a proper water supply at an
adequate ow.
WARNING: Risk of eye injury.
Spray can splash back or propel objects.
Always wear indirect vented (chemical •
splash) safety goggles marked to comply
with ANSI Z87.1 when using or in vicinity of
this equipment.
NEVER substitute safety glasses or dry-•
condition goggles for indirect vented
safety goggles.
NOTICE: Using a One Way Valve (vacuum
breaker or check valve) at pump inlet can
cause pump or inlet connector damage.
There MUST be at least ten feet of •
unrestricted garden hose between the
pressure washer inlet and any device, such
as a vacuum breaker or check valve.
Damage to equipment resulting from failure to •
follow this instruction will void warranty.
Figure 8
Figure 9
D
Figure 7
C
