Task Force 26153 - Operation; Cutting Height Adjustments; Align Cutting Path

Cutting height adjustments: (Fig.10 )
The cutting height of the mower adjusts from 1-5/8 - 2-5/8 in. (4.3-6.8cm) with 9 positions for adjustment height by
adj
ustment levers to the required position.
To achieve the lowest cutting position, one at a time, move the the adjustment levers on both
sides, located next to the
smal
ler wheels, up to the highest position.
To achieve the highest cutting position, move the adjustment levers on both sides to their lowe
st position.
Other
cutting heights are achieved by moving the adjustment levers to any stop between the highest and lowest positions.
NOT
E: The two adjustment levers MUST
be set to the same position (height).
Height adjustment
OPERATION
Fig.10
8
moving the height
NOTE: Do not use wheels as a reference point for grass cut line.
ALIGN CUTTING PATH INDICATION ARROW WITH PREVIOUSLY CUT PATH (Fig. 11)
Fig. 11
