TASKalfa 4002i - Page 597

To Next Page

To Previous Page

10-98

Troubleshooting > Clearing Paper Jams

Press the release lever to pull the folding unit out.

Open the folding unit left cover.

Turn dial (D9).

Remove any jammed paper.
