TASKalfa 6002i - Page 609

To Next Page

To Previous Page

10-110

Troubleshooting > Clearing a Staple Jam

Remove paper from inside the finisher.

Remove the Staple Cartridge Holder (B) or (C).

Remove the jammed staple.

Install the Staple Cartridge Holder (B) or (C).
