2-5

Installing and Setting up the Machine > Part Names (With Optional Equipments Attached)

Part Names (With Optional Equipments

Attached)

1 Tray 1 to 7 (tray 1 is the top tray)

2 Tray A

3 Tray B

4 Job Separator Tray

5 Folding Tray

6 Cassette 3

Optional Equipment (page 11-2)

7 Cassette 4

8 Cassette 5

9 Finisher Tray

10 Job Separator Tray

11 Original Cover

12 Control Section of the Finisher

Manual Staple (page 5-71)
