5
Overview
1 Height adjustment for handle height
2 Recovery tank maintenance opening
(red mark)
3 Cleaning solution tank opening
maintenance
4 Squeegee lowering device
5 Squeegee
6 Squeegee adjustment
7 Squeegee pressure adjustment
8 Lever for reversing the air flow
(only co 15/1700)
9 Brush unit
10 Machine hood
11 Lever brush unit
(only co 14/16/1800)
12 Machine handle
13 Speed control
1
2
3
8
9
10
11
567
4
13 12
