Taski vacumat 12 - Structural Layout

68
Structural layout
1 On/Off switch
2 Tilting chassis with bumper
3 Height adjustment screws (fixation of bumper)
4 Carrying handle
5 Suction hose release
6 Intake
7 Tank
8 Squeegee
9 Fixomat squeegee hose connector
10 Filter basket
11 Filter cloth
12 Float housing
13 Suction hose for Fixomat squeegee
14 Snap handle
15 Vacuum lid
16 Carrying handle
1 16 15
12
14 13
2
8 9 10 11
3
4
5
6
7
