23
Checkwiring,checkthemotorrotatesfreelyandispowereddirectlybythe
battery,checkfuseF5;
5 (red) ashes + :
max current limit for motor exceeded;
Excessiveabsorptionpeaksofthegearmotor,checktherearenoobstacles
ontheautomationpath,checkthecurrentabsorptionofthemotorwhenin
ano-loadconditionandwhenappliedtothegate,
6 ashes (orange):
master/slave communication error;
Checkwiringbetween the controllers, eciencyofslave controller (fuses),
eciencyofinterfaceboards;
7 ashes (red):
Sensitive edge safety intervention
A command pulse is required to carry out the closure;
8 (red) ashes:
Eeprom external memory fault;
Replacetheexternalmemorymodule;
8 (orange) ashes:
Eeprom data error (internal/external);
PerformprocedureRADIOMEMORYRESET;
Apart from the logic mistakes, the DL2 LED indicates also the status of the control unit during the
saving of the radio controls.
always on (green):
channel CH1 waiting to be saved;
5 quick ashes (green):
CH1 channel memory full;
always on (Orange):
channel CH2 waiting to be saved;
5 quick ashes (Orange):
CH2 channel memory full;
always on (red):
channel CH3 waiting to be saved;
5 quick ashes (red):
CH3 channel memory full;
ashing (green):
CH1 channel waiting to be cancelled;
always on (green):
cancelling of channel CH1 in progress;
ashing (Orange):
CH2 channel waiting to be cancelled;
always on (Orange):
cancelling of channel CH2 in progress;
ashing (red):
CH3 channel waiting to be cancelled;
always on (red):
cancelling of channel CH3 in progress;
When LEDs DL1 and DL2 ash at the same time they indicate:
ashing + : (Green + Red)
factory reset procedure waiting for conrmation;
ashing + : (Green + Orange)
waiting for total cancellation of the radio channels;
DL3 - Red PEDESTRIAN button LED signal
DL4 - Red OPEN/CLOSE button LED signal
DL5 - Green STOP button LED signal
DL6 - Green INTERNAL PHOTOCELLS LED signal
DL7 - Green EXTERNAL PHOTOCELLS LED signal
DL8 - Green SENSITIVE EDGE LED signal
Multiple errors are signalled by a 2-second pause between signals.
Should the encoder (obstacle detection) activates while closing, the controller will reverse the direction
and slowly open until the laef reaches its fully opened position. Auto Close function will be deactivated
until a further command pulse is given. In case of 5 consecutive safety interventions the controller will
progressively increase the Auto Close delay. Once the closing has been succesfully achieved, the Auto
