tau K124MA - Power Supply

3
FR
RALL
TCA
CH2
PROG
CH1
F2
10A
F1
3.15A
DL6
DL5
DL4
DL3
DL2
DL1
DL8
E1
LED ENCODER
LFCA LFCC
DL7
1 2 3 4 5 6 7 8 9 10 11 12
K124MA
1 2 3 4 5 6 7 8 9 10 11 12
Dip-switchesON
DL6
DL5
DL4
DL3
DL2
DL1
DL8 FIXED SAFETY EDGE
EXT. PHOTO
INT. PHOTO
STOP
OPEN/CLOSE
PEDESTRIAN
ERRORS
DL7
TCA
+
-
FR
RALL
Trimmer:
+
-
+
-
TRASF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
J2
22
2324252627
J6
M
+5V ENC
-
GND
J4
J3
Open/Close
Stop Release safety microswitch
Common
Common
Pedestrian
Int. Photocell
Fixed safety edge
-
-
-
-
-
Fototest
+ 24V
Ext. Photocell
Common
External
Photocells
RX
1 2 3 4 5
TX
1 2
Internal
Photocells
RX
1 2 3 4 5
TX
1 2
Flashing
light
24V DC
max. 20W
+ 24 V
+ 24 V
Gate open
warning light
max. 3W
2nd radio
channel
Limit
switch
(optional)
Aerial
Courtesy light
24V 3W max.
FS1
TRANSFORMER
FS2
-
+
LEDs:
F 6,3A
FUSE
POWER SUPPLY
230V ~ 50Hz ± 10%
Battery
Charger
BATT
- Morsetti 1 - 2: Attenzione a NON invertire la polarità.
- Se il jumper J6 è inserito, verrà attivata la modalità basso consumo e, al termine di
ogni manovra, le uscite 11-12, 12-13, 14-15, 16-17 e 16-18 verranno spente.
- Terminals 1 – 2: Careful NOT to invert polarity.
- If Jumper J6 is plugged in, energy saving mode will be activated and, at the end of
each manouvre, outputs 11-12, 12-13, 14-15, 16-17 and 16-18 will be switched o.
- Klemmen 1 - 2: Achtung: Nicht verpolen.
- Wenn der Jumper J6 eingesteckt ist, wird die Modalität Energiespar aktiviert und am Ende
jedes Manövers werden die Ausgänge 11-12, 12-13, 14-15, 16-17 und 16-18 abgeschaltet.
- Etaux 1 - 2: Assurez-vous de NE PAS inverser la polarité.
Si le cavalier J6 est pas inséré, la fonction modalité consommation réduite sera
activée et, à la n de chaque manœuvre, les sorties 11-12, 12-13, 14-15, 16-17 e
16-18 seront désactivées.
- Bornes 1 - 2: Tenga cuidado en NO invertir la polaridad.
- Si el puente J6 está insertado, se activará el modo de bajo consumo y, al nal de cada
maniobra, las salidas 11-12 , 12-13 , 14-15 , 16-17 y 16-18 se desconectarán.
- Terminais 1 – 2: Cuidado NÂO inverter a polaridade.
- Se o jumper J6 está conectado, ele irá alternar para o modo de baixo consumo de energia
e, ao nal de cada manobra, as saídas 11-12, 12-13, 14-15, 16-17 e 16-18 serão desligados.
K124MA
