1 UPRRIGHT FRAME 1
2 PULLEY WHEEL LOGO PLATE BDE7144 4
3 ROUND HEAD CROSS TAPPING SCREW M2x6 12
4 PULLEY WHEEL PBG107 8
5 BEARING 6202Z 12
6 PLASTIC PULLEY COVER PCZ3535 12
7 OIL BEARING NBZ201588 24
8 PULLEY BRACKET GUARDS FRAME 2
9 IRON PLATE NAB081419328 1
10A FRONT TOP COVER CAP PCZ36040A 1
10B FRONT BOTTOM COVER CAP PCZ36041C 1
11 PLATE SHROUD(R) PCZ36040B 2
12 ALUMINIUM LOGO PLATE BDE22835 1
13 TRUSS CROSS TAPPING SCREW Ø3.5x10 12
14 END CAP PAA60469 6
15 ROUND HEAD CROSS SCREW M6x35 4
16 BACK REST/SUPPORT TUBE 1
17 CROSS BAR 1
18 BACK REST HANDLE BAR 1
19 FOAM GRIP Ø31.4xØ25.4x450 1
20 ALLEN BOLT M8x40 2
21 END CAP PAB2515 2
22 OVAL CAP 40x80x2.0t 2
23 Rubber padding pulley shround 2
24 ALLEN BOLT M10x47(12mm) 4
25 ACORN NUT M10 20
26 BASE FRAME 1
27 PERFORATED COVER NAI30713400 1
28 BASE PLATE FLOOR PAD PBZ450 9
29 ROLLER PBG40C 2
44
Ultra Force
8.2 Parts List
No. Name (ENG) Specication Qty.
