the size is not known insert the bit into the collet. The collet which offer a machine t to the shank is
the correct one to use. Do not force the bit into a collet. Replace the spring and place the collet into
the spindle before loosely replacing the nut (H). Slide in the bit allowing approx. 5-10mm overhang
before tighten the collet nut (observe the router bit’s manufacturers instructions for more specic
information).
NOTE:
Ensure at least 75% of the shank is inside the collet. Do not tighten the collet with no bit
tted as this will cause damage. Do not over tighten the collet nut.
WARNING:
Take care when handling the cutter bits as they are extremely sharp. When
cutting is complete remove the bit before cleaning and storing it in a safe place.
OPERATING INSTRUCTIONS
NOTE:
Remove the plug form the socket before carrying out adjustment, servicing or
maintenance.
TIGGER
SWITCH
(FIG.
4):
The router is tted with a safety lock off switch to prevent
accidental starting. Press and hold lock button (K). Pull
trigger (L) and the router will start.
VARIABLE
SPEED
DIAL
(Fig.
5):
The variable speed dial is marked 1 to7 and the marks
express speed from min. to max.
NOTE:
Cutting speed depends on material, cutter size,
cutting depth etc. larger router bits will require a slower
speed. For more detailed information refer to a routing/
woodworking book.
