GETTING TO KNOW YOUR ROUTER
1. ON/OFF trigger switch 11. Height adjustment lock
2. Trigger safety button 12. Collet nut
3. Plunge lock level 13. Turret
4. Additional rod locking point (used in
conjunction with 16)
14. Rods
5. Rod locking poin 15. Collets
6. Spindle lock button 16. Pivot rod trammel
7. Variable speed dial 17. 16-18mm template follower
8. Cable sleeve 18. Spanner
9. Fine height adjustment control 19. Parallel guide fence
10. Height adjustment scale 20. Dust extraction port (xed on machine)
