Taylor TX180S - Page 281

TX / TXH / TXB 180S - 400L (Rev. 4/23/07)TX / TXH / TXB 180S - 400L (Rev. 4/23/07)
27-427-4
BACK RESTBACK REST
SLIDE BLOCKSLIDE BLOCK
Illustration 27-2. Illustration 27-2. Back Rest Back Rest Slide BlocksSlide Blocks

SLIDESLIDE
BEARINGBEARING
BLOCKBLOCK
SLIDESLIDE
BEARINGBEARING
HOUSINGHOUSING
SHIMSHIM
REPLACE BEARING BLOCKS WORNREPLACE BEARING BLOCKS WORN
TO 1-3/4” (44.5 mm) THICK OR BLOCKSTO 1-3/4” (44.5 mm) THICK OR BLOCKS
THAT ARE CRACKED OR BROKENTHAT ARE CRACKED OR BROKEN
1-3/4” (44.5 mm)1-3/4” (44.5 mm)
MINIMUMMINIMUM
Illustration 27-3. Illustration 27-3. Slide Bearing Slide Bearing Block ReplacBlock Replacementement
