Major Components Locations
Major Components Locations
TX / TXH / TXB 180S - 400L (4/07)TX / TXH / TXB 180S - 400L (4/07)
HYDRAULIC TANKHYDRAULIC TANK
(Section 22)(Section 22)
MASTMAST
(Section 27)(Section 27)
TILT CYINDERSTILT CYINDERS
(Section 22)(Section 22)
CARRIAGECARRIAGE
(Section 28)(Section 28)
DRIVE AXLEDRIVE AXLE
(Section 14)(Section 14)
DRIVE SHAFTDRIVE SHAFT
(Section 11)(Section 11)
TRANSMISSIONTRANSMISSION
(Section 9)(Section 9)
FUEL TANKFUEL TANK
(Section 2)(Section 2)
STEER AXLESTEER AXLE
(Section 13)(Section 13)
ENGINEENGINE
(Section 1)(Section 1)
RADIATORRADIATOR
(Section 5)(Section 5)
