8 Technical Data
8 Technical Data
TECHNICAL DATA UNIT LN 230 LN 260 LN 265
Air volume flow free blow
max.
m³/h 320 320 700
Effecitve air volume flow
max.
m³/h 50-250 50-250 50-540
Max. stat. pressure Pa 20000 20000 15000
Filter surface m² See filter configuration
Motor performance ca. kW 1,1 1,1 1,8
Voltage V 120/230 120/230 120/230
Frequency Hz 50/60 50/60 50/60
Protection class - 1 1 1
IP Protection class - IP 30 IP 30 IP 30
Motor type - Brushless motor Brushless motor Brushless motor
Noise level db(A) ca. 62 ca. 62 ca. 65
Serial interface - Sub-D 25 Sub-D 25 Sub-D 25
Weight
Filter Standard, A, Z
Filter ZA, M
Filter TZA
Filter MP
kg
ca. 40
ca. 55
ca. 70
ca. 42
ca. 70
ca. 90
ca. 110
ca. 70
ca. 70
ca. 90
ca. 110
ca. 70
Dimensions (H/B/D)
Filter config. A
Filter config. Z
Filter config. ZA
Filter config.TZA
Filter config. M
Filter config. MP
mm 700/350/350
700/350/350
700/350/350
930/350/350
1170/350/350
1030/350/350
690x350x350
740/350/ 655
740/350/ 655
740/350/ 655
1010/350/655
1280/350/655
1065/350/655
770x350x655
740/350/ 655
740/350/ 655
740/350/ 655
1010/350/655
1280/350/655
1065/350/655
770x350x655
Intake socket DN 50 mm 2 2 2
Intake socket DN 80 mm 1 1 1
Intake socket DN 100 mm 1 - -
Intake socket DN 125 mm - 1 1
Filter configuration*
Filter type Filter class A Z ZA TZ
A
M M
P
A Z ZA TZ
A
M M
P
A Z ZA TZ
A
M M
P
Pre-filter
Particle filter
F 5
H 13
- - - - - - - - - - - - - - - - - - - - -
Al filter G 3 - - - - - - - - - x x x - - - - x x x - -
Pre-filter F 5 x x - - - - - x x x x - - - x x x x - - -
Bag filter F5/F6 - - - - x - - - - - - x - - - - - - x - -
Z-Linepanel filter F7 - - x x x - - - - x x x - - - - x x x - -
Particle filter H13 x - x x x x x x - x x x x x x - x x x x x
MP-Tech F 7 - - - - - x x - - - - - x x - - - - - x x
Activated carbon 7L
10L
18L
26L
45L
-
x
-
-
-
-
-
x
-
-
-
-
-
-
-
-
-
x
-
-
-
-
x
-
-
-
x
-
-
-
-
-
-
-
-
-
-
-
x
-
-
-
-
-
x
-
-
-
-
-
-
-
-
-
x
-
-
-
-
x
-
-
-
x
-
-
-
-
-
-
-
-
-
x
-
-
-
-
-
x
-
-
-
-
-
-
-
-
-
x
-
-
-
-
x
-
-
-
x
-
-
-
-
-
-
* dependent on filter equipment
83-236
