EUM/OPS/MAN/15/776259
v2B e-signed, 10 May 2021
TBS DVB-S2 Receivers EUMETCast LINUX Setup Guide
Page 12 of 15
Figure 11 TBS-6903/6908 Power Cable
The connectors used in the TBS-6903/6908 devices configuration are described in the
following table:
Number
Connector
1
PCIe 1.x Connector
2
RF In
3
Power Cable Connector
Notes:
i. On TBS-6903/6908 to get adapter 0 use the lower plug.
ii. The external power plug is optional. It needs to be used in very rare cases when there is
no enough power from PCIe slot. (The LNB Input on TBS cards can provide 450mA. If
the user has only LNB connected on the coaxial cable, then the external power is not
needed as one LNB is on average 100mA. If there are things like motor, DiSEqC devices
on the same coaxial cable, then the power consumption can go up and external power be
needed).
4.2 Linux Drivers
1) Precompiled drivers are not available
2) You can find the latest linux driver at tbsdtv web site :
http://www.tbsdtv.com/download/
It is recommended to select “Open Source Linux Driver” and follow the instructions using
the “Downloading and building” and “Firmware” installation, using the following link
https://github.com/tbsdtv/linux_media/wiki
3) After the driver installation reboot the EUMETCast W/S in order to load the newly
