TBS DVB-S2 Receivers EUMETCast LINUX Setup Guide
Page 9 of 15
Figure 7 TBS-5925/5927 Connectors
The connectors used in the TBS-5925 device configuration are described in the following
table:
Number
Connector
1
Power Supply
2
RF In
3
USB 2.0 Connector
 Connect the power adaptor to connector 1 on the TBS-5925;
 Connect the antenna cable to the connector 2 ;
 Connect the device using the connector 3 to the PC using a usb cable ;
