Disassembly procedure for CPU board
Make a backup of the user presets.
Disconnect power
Remove the top cover and the bottom cover.
Remove the 3 cables to the CPU-PCB. The 3 cables are connected to J2, J3 and J4. See fig. 1.
J2
J4
J3
Front
