TC Electronic D-TWO User Manual

8
REAR PANEL
IN
UL6500
EN/IEC 60065
PROFESSIONAL AUDIO EQUIPMENT
THRU
INLEFT LEFTRIGHT RIGHT
OUT
MIDIBALANCED INPUTS BALANCED OUTPUTS DIGITAL I/O PEDAL
DI
DO
S/PDIF
SERIAL NO.
TYPE: MAN001
TC ELECTRONIC
MADE IN THAILAND
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK DO NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE
AVI S:
RISQUE DE CHOC ELECTRIQUE-NE PAS
OUVRIR.
100-240VAC
50-60Hz, 15W
CAUTION
R
CUS
THIS CLASS B DIGITAL DEVICE MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE-
CAUSING EQUIPMENT REGULATIONS AND COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION SUBJECT TO CONDITIONS STATED IN THE MANUAL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Balanced
Jack
Analog
Inputs
Pedal
Input
MIDI
In/Out/Thru
Balanced
Jack
Analog
Outputs
Digital
S/PDIF
Input/
Output
Power
Input
100 - 240V
Serial
Number
Sleeve - Pin 1 (Ground)
Tip - Pin 2 (Hot)
Ring - Pin 3 (Cold)
Sleeve - Pin 1 (Ground)
Tip - Pin 2 (Hot)
Sleeve - Pin 3 (Cold)
Jack (unbalanced) - XLR
Jack (balanced) - XLR
TIP
RING
GND
TIP
GND
MIDI Cable
DIN CONNECTOR
5POLE - MALE
45 degrees
DIN CONNECTOR
5POLE - MALE
45 degrees
max. 10m
SHIELDED CABLE (3 or 5 wires + screen)
(Use Left Input
for Mono
connection)
