TC Electronic HyperGravity Compressor User Manual

Technical specifications
English manual 2015-09-28 26
Please note that due to continuous development, the following specifications are subject to change without further notice.
Bypass mode True Bypass (Buffered Bypass optional)
Dimensions (width x depth x height) 48 x 48 x 93 mm – 1.9 x 1.9 x 3.7”
Input connector Standard ¼” jack – mono/TS
Output connector Standard ¼” jack – mono/TS
Power input Standard 9V DC, centre negative >100mA (power supply not included)
Battery option -
Input impedance 1MΩ
Output impedance 100Ω
USB port Mini USB connector for uploading and editing custom TonePrints and for software updates

TC Electronic HyperGravity Compressor Specifications

General

Brand	TC Electronic
Model	HyperGravity Compressor
Category	Music Pedal
Language	English
