32 M10 0 33Quick Start Guide
Speci cations
Inputs
Type ¼ " TS connectors, unbalanced
Impedance approx. 7.5 kΩ
Output
Type ¼ " TRS connectors, impedance balanced
Impedance approx. 220 Ω
Max. output level +10 dBu
In/Out
Type ¼ " TS footswitch connector
Digital Processing
Converters 24-bit Delta-Sigma, 128-times oversampling
Sampling rate 48 kHz
System Speci cations
Frequency response 10 Hz to 22 kHz, -3 dB
Dynamic range 96 dB, 10 Hz to 22 kHz
Distortion 0.01% typ. @ 0 dBFS
Crosstalk -76 dB @ 1 kHz
Signal-to-noise ratio 10 Hz to 22 kHz >86 dB @ 0 dBu, A-weighted
Power Supply
Mains connection external power supply, 12 VDC, 400 mA
Mains voltage
USA/Canada 120 V~, 60 Hz
U.K./Australia 240 V~, 50 Hz
China 220 V~, 50 Hz
Europe 230 V~, 50 Hz
Japan 100 V~, 50-60 Hz
Power consumption approx. 3.5 W
Physical
Dimensions (H x W x D) 46 x 191 x 99 mm (1.8 x 7.5 x 3.9")
Weight 0.6 kg (1.3 lbs)
