9
EN
or just one are being used. Use the left output in a
mono setup. In this case, the stereo-sensing feature
will send delay repeats intended for both outputs to the
left output when the right output is left unplugged.
Connections
1 – Power
NOVA Repeater requires 9-12V DC 300 mA. We
recommend using the supplied 12V power-supply or a
power-supply with identical specifications. Please note
that NOVA Repeater’s dynamic input range is reduced
if only 9V are supplied. This is only an issue if you use
a drive or boost pedal prior to NOVA Repeater and
crank the output of that pedal hard.
2/3 – HI IN & LO IN – Inputs
NOVA Repeater has two input options: LO and HI.
Which input to use depends on how “hot” a signal you
connect. If the signal has passed a preamp or a hot
boost/drive pedal, use HI. Otherwise, use LO. But you
can simply try both and let your ears decide.
4 – R OUT & L OUT – Outputs
These are 1/4" mono jack connectors. Use both
outputs for stereo or the left output if you only need a
mono signal. The outputs have a stereo-sensing
feature that automatically detects whether both outputs
Controls
5/10 – DELAY Knob and DELAY RANGE Table
The DELAY knob adjusts the delay time. Turn counter-
clockwise to reduce and clockwise to increase the
delay time. The maximum delay time varies depending
on the selected delay range. You can step through the
three delay ranges by clicking the RANGE button. The
options are:
6 – FEEDBACK Knob
The FEEDBACK knob sets the amount of delay
returned to the input of the delay line. The higher the
setting, the more repeats you get.
OPERATION
