TC Electronic Sentry Noise Gate User Manual

Technical specifications
English manual 2015-09-28 27
Please note that due to continuous development, the following specifications are subject to change without further notice.
Bypass mode True Bypass (Buffered Bypass optional)
Dimensions (width x depth x height) 48 x 48 x 93 mm – 1.9 x 1.9 x 3.7”
Input connector Standard ¼” jack – mono/TS + Return jack
Output connector Standard ¼” jack – mono/TS + Send jack
Power input Standard 9V DC, centre negative >100mA (power supply not included)
Battery option -
Input impedance 1MΩ
Output impedance 100Ω
USB port Mini USB connector for uploading and editing custom TonePrints and for software updates
