TC Electronic VORTEX FLANGER User Manual

13
will most likely be to activate the buffer in the first and last pedal in the signal chain. Can you hear the
differencebetweenapedalinTrueBypassorBufferedBypass?Maybe,maybenot,–manyfactors
apply.Active/passivepick-ups,singlecoil/humbucker,cablequality,ampimpedanceandmore.We
cannot give a single ultimate answer. Use your ears and find the best solution for your setup!
Kill-Dry on/off – With Buffered Bypass activated (upper switch to the right), the lower dip-switch sets
Kill-Dry on/off. Kill-Dry removes all direct signal from the pedals output and is the mode to use when
the pedal is placed in a parallel effects loop.
Kill-DryisNOTanoptioninTrueBypassmode.
Changing battery - Unscrew the thumb-screw on the back of the pedal and detach the back-plate.
Un-mount the old battery and attach the new battery to the battery clip making sure the polarity is
correct.Thenremounttheback-plate.Tosavebatterylife;removetheinputjackwhenyoudon’tplay.
Batteries must never be heated, taken apart or thrown into fire or water. Only rechargeable
batteries can be recharged. Remove the battery when the pedal is unused for a longer period of
time. Dispose batteries according to local laws and regulations.

TC Electronic VORTEX FLANGER Specifications

General

Material	Metal
Best uses	Guitar
Product type	-
Product color	Purple
Status LED indicator	Yes
Battery voltage	9 V
Power source type	Battery, DC

Weight and Dimensions

Depth	122 mm
Width	72 mm
Height	50 mm
Weight	300 g
