TC Electronic VORTEX FLANGER User Manual

14
2amazingflangereffects:A1:1recreationofthelegendaryTCElectronicChorus/Flangerpedal
and a classic tape flanger for those psychedelic studio-style flange effects
Unique,newTonePrintsettingforstuffingCoronaChoruswithyourfavoriteartist’stones
72 mm x 122 mm x 50 mm - 300 g (excl. battery)
DualSupplyRailstechnologyensuresheadroomforlineleveleffectloopsfromasingle9V
battery.BatteryfailurecircuitautomaticallyputsVortexFlangerintotruebypassmodeifthe
battery runs out
Custom ‘hammerhead’ rugged, die-cast aluminum casing built for a life on the road
Unique one-screw battery access for lightning fast battery changes
Stereo inputs with automatic mono/stereo sensing – feed it any signal
Stereo outputs for that ultra-wide flanger sound
MiniUSBconnectorforuploadingcustomTonePrintsandsoftwareupdates
Speed,Depth,FeedbackandDelayTimeknobswithhigh-quality,metal-shaftpotentiometers
Heavy duty tactile footswitch with true bypass for zero tone coloration
USBcableforuploadingTonePrints,Owner’sManual,TCElectronicGuitarPamphlet,TC
Electronic Sticke.
These specifications are subject to change without notice
Sounds
Size & Weight
Battery
Design
Connectors &
Inputs/Outputs
Knobs etc.
In the box
(EN) Technical Specifications

TC Electronic VORTEX FLANGER Specifications

General

Material	Metal
Best uses	Guitar
Product type	-
Product color	Purple
Status LED indicator	Yes
Battery voltage	9 V
Power source type	Battery, DC

Weight and Dimensions

Depth	122 mm
Width	72 mm
Height	50 mm
Weight	300 g
