Service Manual TCL Communication Ltd.
Rev.: 1.0
TCL 20 R 5G T767H Service Manual V1.0
Page: 13/19
Confidential and proprietary information contained in this repair guide is subject to change without notice.
Distribution, transfer, copy of any content or data in this document without the written permission of TCL is strictly prohibited.
7. Troubleshooting
7.1. What should I do if my device reboots by itself?
a) If the issue appears occasionally, it may be caused by anomalies in a file. It is recommended that
you continue to use the device normally.
b) Check if the issue occurs during charging. If yes, we recommend trying the official charger and
data cable.
c) If the issue occurs while using a third-party app, make sure the app is compatible with your
device and Android version. Try uninstalling the third-party app.
d) If the issue occurs while using the built-in app, try to reset or update your device.
7.2. What should I do if my device system lags or freezes?
a) Try to restart your device.
b) Charge your device until the battery level is at least 20%.
c) Too many apps running in the background or the system cache not being cleared may cause a
system lag. Touch the Menu key at the bottom corner of screen to view recently used applications.
Touch “Clear all” to close the tasks.
d) Uninstall unused apps from time to time to ensure that your device has sufficient storage space.
e) If the issue occurs in third-party apps, please uninstall the third party apps responsible.
f) If you are playing a game, watching online video or listening to online music, your device may lag
or freeze because of a poor network connection. Enable Airplane mode for a few minutes, then
disable it and check your network connection again. Alternatively, move to a location with a better
network connection
g) Try to reset or update your device.
7.3. What should I do if my device cannot charge or charges slowly?
a) Check if there is any visible damage to the charger USB, the charger itself or the charging port of
your device. If yes, back up your data and take your device and proof of purchase to our repair
center to get more professional technical assistance.
b) Charge the device with a TCL official charger for at least 30 minutes, then try again.
c) Verify whether there are any third-party power management software apps downloaded. If so,

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 20 R 5G and is the answer not in the manual?

TCL 20 R 5G Specifications

General IconGeneral
Cables includedUSB
AC adapter power10 W
AC adapter includedYes
Processor cores8
Processor modelDimensity 700
Processor familyMediaTek Dimensity
Processor frequency- GHz
Processor architectureARM Cortex-A76+Cortex-A55
Processor boost frequency2.2 GHz
RAM capacity4 GB
Memory card slot typeHybrid slot
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size1024 GB
Internal storage capacity64 GB
Color nameLazurite Blue
Form factorBar
Product colorBlue
International Protection (IP) codeIP52
PlatformAndroid
Google applicationsGmail, Google Chrome, Google Maps, Google Photos, Google Play, YouTube
Operating system installedAndroid 11
Panel typeLCD
Screen shapeFlat
Pixel density268 ppi
Display diagonal6.52 \
Touchscreen typeCapacitive
Display brightness500 cd/m²
Display resolution720 x 1600 pixels
Native aspect ratio20:9
Maximum refresh rate90 Hz
Contrast ratio (typical)1200:1
Flash typeLED
Image stabilizerNo
Rear camera typeTriple camera
Front camera typeSingle camera
Maximum frame rate30 fps
Video recording modes1080p
Rear camera pixel size1.12 µm
Rear camera aperture number2.2
Front camera aperture number2
Second rear camera pixel size1.75 µm
Video capture resolution (max)1920 x 1080 pixels
Rear camera resolution (numeric)13 MP
Second rear camera lens elements3-element lens
Front camera resolution (numeric)8 MP
Macro camera resolution (numeric)2 MP
Second rear camera aperture number2.4
Rear camera field of view (FOV) angle76.7 °
Front camera field of view (FOV) angle80.6 °
Third rear camera field of view (FOV) angle88.8 °
Second rear camera field of view (FOV) angle85 °
Graphics cardMali-G57 MC2
Talk time (3G)- h
Battery voltage5 V
Battery capacity4500 mAh
Standby time (4G)506 h
Battery recharge time3.5 h
Continuous audio playback time210 h
Continuous video playback time10 h
USB version2.0
USB connector typeUSB Type-C
Headphone connectivity3.5 mm
SpeakersMono
Audio formats supportedAAC, ADPCM, AMR-NB, AMR-WB, APE, FLAC, MIDI, MP3, Vorbis, WAV
Video formats supportedH.264, HEVC, MPEG4, VP8, VP9
4G standardLTE
3G standardsUMTS
SIM card typeNanoSIM
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.1
3G data rate (max)42 Mbit/s
4G data rate (max)390 Mbit/s
SIM card capability-
Mobile network generation5G
Subscription typeNo subscription
Multimedia Messaging Service (MMS)Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Weight and Dimensions IconWeight and Dimensions
Depth8.99 mm
Width75 mm
Height164.3 mm
Weight186 g
