<Document ID> © NXP B.V. 2007. All rights reserved.
Product data sheet Rev. 0.11 — 25 January 2007 11 of 230
NXP Semiconductors
UOC-TOP-64 N1 series
Signal processor for CRT TV
6. Pinning information
Table 6: Pinning information
SYMBOL SDIP64 DESCRIPTION
AV-110
Mono-110
AV-90 Mono-90
IFVO/SVO/PIP
[3]
11 IF video output / selected CVBS output / PIP output
IFVO/SVO
[3]
1 IF video output / selected CVBS output
VP2 2 2 2 2
nd
supply voltage TV processor (+5 V)
VCC8V 3 3 3 8 Volt supply for audio switches
PLLIF 4 4 4 IF-PLL loop filter
GND2 5 5 5 ground 2 for TV processor
DECSDEM 6 6 6 decoupling sound demodulator
AVL/SSIFOUT/SNDDEMOUT
[2]
7 7 7 AVL / Second sound IF output / sound demodulator output
EHTO 8 8 8 EHT/overvoltage protection input
AGCOUT 9 9 9 tuner AGC output
IREF 10 10 10 reference current input
VSC 11 11 11 vertical sawtooth capacitor
VIFIN2 12 12 12 IF input 2
VIFIN1 13 13 13 IF input 1
VDRA 14 14 14 vertical drive A output
VDRB 15 15 15 vertical drive B output
EWD/AVL 16 East-West drive output / AVL capacitor
AVL 16 16 AVL capacitor
DECBG 17 17 17 bandgap decoupling
SECPLL 18 18 18 SECAM PLL decoupling
GND1 19 19 19 ground 1 for TV-processor
PH1LF 20 20 20 phase-1 filter
PH2LF 21 21 21 phase-2 filter
VP1 22 22 22 1
st
supply voltage TV-processor (+5 V)
DECDIG 23 23 23 decoupling digital supply
XTALOUT 24 24 24 crystal oscillator output
XTALIN 25 25 25 crystal oscillator input
P1.5 26 26 26 port 1.5
P3.3/ADC3/PWM3 27 27 27 port 3.3 or ADC3 input or PWM3 output
P3.2/ADC2/PWM2 28 28 28 port 3.2 or ADC2 input or PWM2 output
P3.1/ADC1/PWM1 29 29 29 port 3.1 or ADC1 input or PWM1 output
P3.0/ADC0/PWM0 30 30 30 port 3.0 or ADC0 input or PWM0 output
P2.1/PWM0 31 31 31 port 2.1 or PWM0 output
P2.0/TPWM 32 32 32 port 2.0 or Tuning PWM output
VDDP(3.3V) 33 33 33 supply to periphery (3.3V)
P1.7/SDA 34 34 34 port 1.7 or I
2
C-bus data line
P1.6/SCL 35 35 35 port 1.6 or I
2
C-bus clock line
P1.3/T1 36 36 36 port 1.3 or Counter/Timer 1 input
P1.1/T0 37 37 37 port 1.1 or Counter/Timer 0 input
P1.0/INT1 38 38 38 port 1.0 or external interrupt 1
INT0/P0.5 39 39 39 external interrupt 0 or port 0.5 (4 mA current sinking capability for
direct drive of LEDs)
VDDC(3.3V) 40 40 40 supply
