1. Enter P-Mode, press key “4” to select page “4”.Set the corresponding item to require
value. See below table 3.7.1 for detailed description.
Table 3.7.1: Producing parameter setup and option page “4”
OSD menu Default Value Description Remark
0=Aging mode off
WARM UP STATUS 0 Set aging mode
1=Aging mode on
SHOP INIT 0 Set the shopping status 0=>1= Set the shopping status
DCXO 2
Crystal oscillator
frequency adjustment
Adjust this value to get the max
color synchronization range.
Don’t adjust, use default value for
producing
0=”FACTORY HOTKEY” off
FACTORY HOTKEY 1 Set factory hotkey
1=”FACTORY HOTKEY” on
ON=On when power on
STB=Standby when power on
POWER ON MODE LAST Set the power on mode
LAST=Last power off status
EEPROM INIT 0 EEPROM initial 0=>1=Active EEPROM initial
POWER LOW
101
Recommended value= “16”
POWER HIGH
176
Set the “Voltage display”
“LOW” and “HIGH”
threshold
Recommended value= “168”
DEFAULT SND. SYS DK
Set the default sound
system when auto store
Set the right value according to the
sales area
0= Blue background for TV and AV
while no signal
1=Black background for TV and AV
while no signal
BLUE BACK OPT 2
Set the Background
option while no signal
2=Snowy background for TV and
black background for AV while no
signal
BLACK BRI 40
Set the black
background brightness
while no signal
Recommended value= “20”
BRI CURVE >> Set the brightness curve
CON CURVE >> Set the contrast curve
COL CURVE >> Set the colour curve
VOL CURVE >> Set the volume curve
Press “►◄” or “VOL+ VOL-” key
to enter a sub-menu to do the
setup, and press “MENU” key the
previous menu
Description:
1). Set the shopping status
When trigger the “SHOP INIT” item form “0” to “1”, the TV will be put on selling status.
The TV status after shopping status:
A. “FACTORY HOTKEY” had set to “OFF”.
