TCL 21M63S-NX56E User Manual

03-DM63NAK-SY12S
21M63S/NX56E-AP/ P/S BG & DK & I
YUV
ASS PART NO. SEPC LOCATION
03-DM63NAK-SY12S T6-NR0002-AAN0X STARWAYASY
03-DM63NAK-SY12S
V8-NX56AP2-
TM3V616
SOFTWARE SOFTWARE CODE IC201(CP)
T8-21APAK-MA1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D454;D404;D401;D301
T8-21APAK-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING)
D406;D601;D316;D315;D204;D210
;D313
T8-21APAK-MA1 10-79C33V-DBX DIODE ZENER 33V 1/2W 5% D101
T8-21APAK-MA1 10-79C4V7-DBX D-PR /A /
_
V 4.7V BZX79C4V7 D314
T8-21APAK-MA1 10-79C5V6-DBX DIODE ZENER 5V6 1/2W 5% D251;D201;D202;D203
T8-21APAK-MA1 10-79C8V2-DBX
D-ZENER BZX55C8V2 8.2V 500MI0W
R=N
D407
T8-21APAK-MA1 10-79C9V1-DBX D-PR /A /
_
V 9.1V BZX79C9V1 D250
T8-21APAK-MA1 11-DA8050-CBS
TR 25V 1.5_A NPN 1W 100MHZ TO-92C
3DA805
Q202;Q201
T8-21APAK-MA1 11-KTD863-0BX TRANSISTOR KTD863 Q401
T8-21APAK-MA1 11-SA1015-YBX
TR 50VV 150MA_A PNP 0.4W 80MHZ
TO-92 ST2
Q601
T8-21APAK-MA1 11-SC1815-YBX
TR 50VV 150MA_A NPN 0.4W 80MHZ
TO-92 2SC
Q210;Q602;Q903;Q904
T8-21APAK-MA1 18-CB0100-JNX RES. C.F. 10 OHM 1/6W +/-5% R217
T8-21APAK-MA1 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5%
R247;R215;R245;R239;R240;R275
;R274;R214
T8-21APAK-MA1 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5%
R256;R250;R101;R272;R241;R246
;R102;R208
T8-21APAK-MA1 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5%
R603A;R242;R927;R271;R928;R40
9;R252;R253
T8-21APAK-MA1 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5%
R228;R614;R415;R303;R302;R213
;R604A
T8-21APAK-MA1 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% R205;R315
T8-21APAK-MA1 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5%
R258;R257;R255;R254;R238;R613
;R612;R610
T8-21APAK-MA1 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% R417
T8-21APAK-MA1 18-CB0122-JNX RES. C.F. 1.2K OHM 1/6W +/-5% R251
T8-21APAK-MA1 18-CB0123-JNX RES. C.F. 12K OHM 1/6W +/-5% R216
T8-21APAK-MA1 18-CB0152-JNX RES. C.F. 1.5K OHM 1/6W +/-5% R311;R605;R606
T8-21APAK-MA1 18-CB0153-JNX RES. C.F. 15K OHM 1/6W +/-5% R201
T8-21APAK-MA1 18-CB0202-JNX RES. C.F. 2K OHM 1/6W +/-5% R407
T8-21APAK-MA1 18-CB0222-JNX RES. C.F. 2.2K OHM 1/6W +/-5% R301;R304
T8-21APAK-MA1 18-CB0223-JNX RES. C.F. 22K OHM 1/6W +/-5%
R905;R611;R902;R249;R406;R903
;R906
T8-21APAK-MA1 18-CB0272-JNX RES. C.F. 2.7K OHM 1/6W +/-5% R211
T8-21APAK-MA1 18-CB0274-JNX
TCL18-CB0274-JNX= RES. C.F. 270K
OHM 1/6
R410
T8-21APAK-MA1 18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% R260
T8-21APAK-MA1 18-CB0332-JNX RES. C.F. 3.3K OHM 1/6W +/-5% R221;R222
T8-21APAK-MA1 18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% R209;R210
T8-21APAK-MA1 18-CB0391-JNX RES. C.F. 390 OHM 1/6W +/-5% R204;R259
T8-21APAK-MA1 18-CB0393-JNX RES. C.F. 39K OHM 1/6W +/-5% R608;R212
T8-21APAK-MA1 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% R224;R220;R223
T8-21APAK-MA1 18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% R401;R202;R921;R922
T8-21APAK-MA1 18-CB0472-JNX
CARBON RES. C.F. 4.7K OHM 1/6W
+/-5%
R270;R219;R229
T8-21APAK-MA1 18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% R206
T8-21APAK-MA1 18-CB0562-JNX RES. C.F. 5.6K OHM 1/6W +/-5% R316
T8-21APAK-MA1 18-CB0563-JNX RES. C.F. 56K OHM 1/6W +/-5% R607
T8-21APAK-MA1 18-CB0680-JNX RES. C.F. 68 OHM 1/6W +/-5% R203
T8-21APAK-MA1 18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% R207
