TCL 21M63S-NX56E User Manual

T8-21M63AK-FC1 54-113970-0U0
TV RAW INSULATOR SLEEVE AWG#5 --
00 00 R
FOR SPK HOUSING
T8-21M63AK-IR1 11-SC1815-YBX
TR 50VV 150MA_A NPN 0.4W 80MHZ
TO-92 2SC
Q011
T8-21M63AK-IR1 18-CB0100-JNX RES. C.F. 10 OHM 1/6W +/-5% R011
T8-21M63AK-IR1 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% R013
T8-21M63AK-IR1 18-CB0122-JNX RES. C.F. 1.2K OHM 1/6W +/-5% R012
T8-21M63AK-IR1 25-BFB220-M1X CAP. ELEC 22 UF 50V +/-20% C012
T8-21M63AK-IR1 26-EBP104-ZFS CAP. CER 0.1UF 50V +80%/-20% C011
T8-21M63AK-IR1 40-N21M63-IRA1XG TV PCB IR BD R=Y
T8-21M63AK-IR1 02-IRR001-XX1T IR RECEIVER 37.9KHZ 5V N HM338A IR011
T8-21M63AK-IR1 46-33079W-02XG PIN BASE *2 TJC3-2A P011 FOR LED
T8-21M63AK-IR1 46-CD050T-04K01G
WIRE 导线 500MM 04 TJC3 SCN 2.5MM
UL#246
S011 TO MD P202
T8-21M63AK-PA10 01-00NX56-MAM9A TV CIRCUIT DIAGRAM -- R=Y 提供线路图20份
T8-21M63AK-PA10 49-R03P80-BAT BATTERY 1.5V
T8-21M63AK-PA10 70-ALKHIA-WAR9C TV PRI GUIDE SHEET TX81 ---- R=N
T8-21M63AK-PA10 71-ALKHIA-BAR8Z TV PRI LABEL -- WHITE & BLACK R=Y
T8-21M63AK-PA10 71-ECL900-109E3 PRI LABEL ---- WHITE & BLACK R=Y 21091000001起
T8-21M63AK-PA10 71-STARWS-SCR9C
TV PRI LABEL SCREEN LABEL WHITE &
BLACK
T8-21M63AK-PA10 72-BASEIS-E009A IB BASE INSTRUCTION TCL CHS R=Y
T8-21M63AK-PA10 72-DM63AE-A129A IB -- -- ARA R=Y
T8-21M63AK-PA10 72-DM63AE-E129J IB -- -- ENG R=Y
T8-21M63AK-PA10 74-022032-6WEEM PRI BAG -- RED 186C 01 00 00 R=N
T8-21M63AK-PA10 74-120120-80HEM PRI BAG -- RED 186C 01 00 00 R=Y
T8-21M63AK-PA10 75-461070-EC0
TV RAW POLYFOAM 75-461070-EC0 --
00 00 R
T8-21M63AK-PA10 75-461080-EC0
TV RAW POLYFOAM 75-461080-EC0 --
00 00 R
T8-21M63AK-PA10 75-461090-EC0
TV RAW POLYFOAM 75-461090-EC0 --
00 00 R
T8-21M63AK-PA10 75-461100-EC0
TV RAW POLYFOAM 75-461100-EC0 --
00 00 R
T8-21M63AK-PA10 76-461110-0AT9S
DEC CARTON-BOX -- CA 00 -- 00
R=Y
T8-21M63AK-RC1 55-455390-5CL6R DEC BACKCOVER -- -- 04 01 00 R=Y
T8-21M63AK-RC1 58-B168SI-2UI9A TV DEC OVERLAY -- -- 01 00 00 R=Y
T8-21M63AK-RC1 58-DM63MP-JKC7M
TV PRI OVERLAY REAR AV
BLACK&WHITE 00 00
T8-21M63AK-RC1 63-B40150-AB4G SCREW-ST 4MM 15MM ISO 62 R=Y MTG R.CAB & F.CAB;MTG FBT
T8-21M63AK-RC1 63-F30100-BT3G SCREW-ST 3MM 10MM ISO 65 0 0 R=Y MTG M.BD & R.CAB
T8-21M63AK-RC1 54-427740-00X FELT TAPE 294X6X0.3
T8-21M63H-BSY 54-420800-000 RUBBER PAD
T8-21M63H-BSY 62-445400-0CL6L
PAI SUPPORT 21E25 BLACK 01 00 00
R=Y
T8-21M63H-BSY 74-045035-50H PLASTIC BAG
T8-21RFLM-FHF4AK 44-21RFLN-SZDA
CRT 21INCH RF NH A51QGD502X001
R=Y
T8-21RFLM-MHF4AK 18-CB0563-JNX RES. C.F. 56K OHM 1/6W +/-5% R459
T8-21RFLM-MHF4AK 18-CB0682-JNX RES. C.F. 6.8K OHM 1/6W +/-5% R416
