EN
9
English
Getting started
Important
:
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like. Remove batteries when
the remote control is not to be used for a long time. Batteries left in equipment may cause damage through
deterioration and corrosive leakage, invalidating the guarantee.
To protect the environment use local recycling facilities for battery disposal. Dispose of used batteries
according to the instructions.
CAUTION
: Risk of explosion if batteries are replaced by an incorrect type. Replace only with the same or
equivalent type recommended by the equipment manufacturer.
If the batteries in your remote control are run down, you can use the buttons on your TV set. They have the
following functions:
For models with below buttons on the set: For models with below buttons on the set:
/
TV mode In menus
P
/
P
Features (Short press)
(Long press)
Features (Long press)
OK
(Short press)
Features (Long press)
OK
(Short press)
For models with below button on the set:
Power on/Standby
Switch the TV on and off
1.
When the power cord is connected, the TV will be turned on directly or be in standby mode. If the TV is in
standby mode, press the or
POWER/
button on the set or the button on the remote control to turn it
on.
2.
To put the TV into standby mode, press the button on the remote control. The TV set remains powered up,
but with low energy consumption.
3.
To switch the TV off, unplug the mains plug from the mains outlet.
Initial setup
The rst time you switch the set on, the
Welcome
screen appears, which guides you through the initial setup
process. Follow the on-screen instructions to nish the initial setup process such as selecting the language,
connecting to the network, scanning channels, and more. During each step, either make a choice or skip the
step. If you skip a step, you can perform the setup later from the settings menu.
Note: If the channel search retrieved only the analogue channels it could be caused by poor broadcasting and
therefore is not covered by manufacturer warranty. Manufacturers cannot be held responsible for lack of
or poor broadcasting in some areas.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 32ES560 and is the answer not in the manual?

TCL 32ES560 Specifications

General IconGeneral
Screen shapeFlat
Response time30 ms
Display diagonal32 \
Display brightness270 cd/m²
Display resolution1366 x 768 pixels
Display technologyLCD
Native aspect ratio16:9
Native refresh rate60 Hz
Peak luminance ratio78 %
LED backlighting typeDirect-LED
Supported video modes768p
Viewable size diagonal800 mm
Contrast ratio (typical)-
Display diagonal (metric)81.3 cm
Motion interpolation technologyPPI (Picture Performance Index) 300
Dynamic contrast ratio marketing nameMega Contrast
HDMI version1.4
RF connector typeF, IEC
Common interface (CI)Yes
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.3
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Video appsNetflix
Smart modesGame, Movie, Sports
Lifestyle appsGoogle Apps
Operating system version9.0
Operating system installedAndroid
Hybrid Broadcast Broadband TV (HbbTV) version1.5
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Audio decodersDolby Digital, Dolby Digital Plus
RMS rated power10 W
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (max)50 W
Power consumption (standby)0.29 W
Power consumption (typical)32 W
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth profilesA2DP, HID
Product colorBlack
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface100 x 100 mm
Processor cores4
Audio formats supportedMP3, WMA
Image formats supportedBMP, JPG, PNG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPEG2, MPG, OGM, TS, VP9, WMV
Picture processing technologyTCL Pure Image Ultra
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
Package depth126 mm
Package height512 mm
Package weight5300 g
Remote control typeRC802N1
CertificationCE
Truck type87 cbm
Pallet width1200 mm
Pallet height1164 mm
Pallet weight107900 g
Pallet net weight12500 g
Quantity per truck1188 pc(s)
Quantity per pallet18 pc(s)
Number of pallets per truck66 pc(s)
Maximum number of stacking cartons5 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)175 mm
Height (with stand)480 mm
Weight (with stand)4000 g
Depth (without stand)80 mm
Width (without stand)732 mm
Height (without stand)435 mm
Weight (without stand)3900 g
