TCL 40 NXTPAPER User Manual

EN
3
Battery
In accordance with air regulations, the battery of your product is not fully
charged. Please charge it first.
- Do not attempt to open the battery (due to the risk of toxic fumes and burns).
- For a device with a non-removable battery, do not attempt to eject or replace
the battery.
- Do not puncture, disassemble, or cause a short circuit in a battery.
- For a unibody device, do not attempt to open or puncture the back cover.
- Do not burn or dispose of a used battery or device in household rubbish or store
it at temperatures above 60°C (140°F), this can result in an explosion or the
leakage of flammable liquid or gas. Similarly, subjecting the battery to extremely
low air pressure may result in an explosion or the leakage of flammable liquid
or gas. Only use the battery for the purpose for which it was designed and
recommended. Never use damaged batteries.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Charger
(1)
Mains powered chargers will operate within the temperature range of: 0°C (32°F)
to 40°C (104°F).
The chargers designed for your device meet the standard for safety of information
technology equipment and office equipment use. They are also compliant with
the ecodesign directive 2009/125/EC. Due to different applicable electrical
specifications, a charger you purchased in one jurisdiction may not work in
another jurisdiction. They should be used for the purpose of charging only.
Model: QC16
Input Voltage: 100~240V
Input AC Frequency: 50/60Hz
Output Voltage: 5.0V/9.0V/12.0V/15.0V/20.0V/3.3-11V
Output Current: 3.0A/3.0A/2.5A/2.0A/1.5A/3A
Output Power: 15.0W/27.0W/30.0W/30W/30W/33W
Average active efficiency: 87.21% (33W)
No-load power consumption: 0.1W
Fast Charging supported protocols: PD3.0 PPS
To enjoy the experience of the Fast Charging technology (33W) supported by this
device,please use a charger compatible with PD 3.0 PPS protocol like the one that
came with the device.
(1)
If you use any other charger, not compatible with PD 3.0 PPS protocol, it will imply
that the smartphone will not use the fast charging technology and the charging
duration may take longer.
(1)
If sold with the device, depending on the device you purchased.

TCL 40 NXTPAPER Specifications

General

Screen shape	Flat
Pixel density	396 ppi
Display diagonal	6.78 \
Touchscreen type	Capacitive
Display brightness	450 cd/m²
Display resolution	1080 x 2460 pixels
Native aspect ratio	20.5:9
Maximum refresh rate	90 Hz
Contrast ratio (typical)	1500:1
Color name	Opalescent
Form factor	Bar
Product color	Pearl
Platform	Android
Operating system installed	Android 13
Audio formats supported	AAC, AAC HE, AMR, FLAC, G.711 A-law, G.711 μ-law, MIDI, MP3, OGG, OPUS, Vorbis, WAV
Video formats supported	H.263, H.264, H.265, MPEG2, MPEG4, VP8, VP9
Graphics card	Mali-G52 MC2
Fingerprint reader	Yes
4G standard	LTE
2G standards	EDGE, GPRS
3G standards	HSPA+
SIM card type	NanoSIM
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.1
SIM card capability	Dual SIM
2G bands (primary SIM)	850, 900, 1800, 1900 MHz
Mobile network generation	4G
USB version	2.0
USB connector type	USB Type-C
Headphone connectivity	3.5 mm
Subscription type	No subscription
User memory	230 GB
RAM capacity	8 GB
Memory card slot type	Dedicated slot
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	2000 GB
Internal storage capacity	256 GB
Rear camera type	Triple camera
Front camera type	Single camera
Maximum frame rate	30 fps
Rear camera pixel size	0.64 µm
Rear camera sensor size	1/2.76 \
Rear camera lens elements	5-element lens
Rear camera aperture number	1.8
Resolution at capture speed	1920x1080@30fps
Third rear camera pixel size	1.75 µm
Second rear camera pixel size	1.12 µm
Second rear camera sensor size	1/5 \
Video capture resolution (max)	1920 x 1080 pixels
Third rear camera lens elements	3-element lens
Rear camera resolution (numeric)	50 MP
Second rear camera lens elements	4-element lens
Front camera resolution (numeric)	32 MP
Third rear camera aperture number	2.4
Second rear camera aperture number	2.2
Rear camera field of view (FOV) angle	74.2 °
Front camera field of view (FOV) angle	71.5 °
Third rear camera resolution (numeric)	2 MP
Second rear camera resolution (numeric)	5 MP
Third rear camera field of view (FOV) angle	88.8 °
Second rear camera field of view (FOV) angle	114.9 °
Processor cores	8
Processor family	MediaTek
Processor frequency	2 GHz
Coprocessor frequency	1.8 GHz
Processor architecture	ARM Cortex-A75
Coprocessor architecture	ARM Cortex-A55
Talk time (3G)	- h
Battery capacity	5010 mAh
Standby time (4G)	630 h
Battery recharge time	1.67 h
Cables included	USB Type-C to USB Type-C
AC adapter power	33 W

Weight and Dimensions

Depth	7.89 mm
Width	75.53 mm
Height	168.16 mm
Weight	195 g
