Page #8 background imageLoading...
Page #8 background image
EN
8
English
Getting started
Important
:
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like. Remove batteries when
the remote control is not to be used for a long time. Batteries left in equipment may cause damage through
deterioration and corrosive leakage, invalidating the guarantee.
To protect the environment use local recycling facilities for battery disposal. Dispose of used batteries
according to the instructions.
CAUTION
: Risk of explosion if batteries are replaced by an incorrect type. Replace only with the same or
equivalent type recommended by the equipment manufacturer.
If the batteries in your remote control are run down, you can use the buttons on your TV set. They have the
following functions:
For models with below button on the set:
Power on/Standby
Switch the TV on and off
1.
When the power cord is connected, the TV will be turned on directly or be in standby mode. If the TV is in
standby mode, press the or
POWER/
button on the set or the button on the remote control to turn it
on.
2.
To put the TV into standby mode, press the button on the remote control. The TV set remains powered up,
but with low energy consumption.
3.
To switch the TV off, unplug the mains plug from the mains outlet.
Initial setup
The rst time you switch the set on, the
Welcome
screen appears, which guides you through the initial setup
process. Follow the on-screen instructions to nish the initial setup process such as selecting the language,
connecting to the network, scanning channels, and more. During each step, either make a choice or skip the
step. If you skip a step, you can perform the setup later from the settings menu.
Note: If the channel search retrieved only the analogue channels it could be caused by poor broadcasting and
therefore is not covered by manufacturer warranty. Manufacturers cannot be held responsible for lack of
or poor broadcasting in some areas.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 40S5200 and is the answer not in the manual?

TCL 40S5200 Specifications

General IconGeneral
Screen shapeFlat
Response time30 ms
Display diagonal40 \
Progressive scanYes
Anti-glare screenNo
Display brightness270 cd/m²
Display technologyLCD
Native aspect ratio16:9
Native refresh rate60 Hz
Peak luminance ratio76 %
LED backlighting typeDirect-LED
Supported video modes1080p
Viewable size diagonal1000 mm
Viewing angle, vertical- °
Contrast ratio (typical)-
Display diagonal (metric)101.6 cm
Screen format adjustments4:3, 16:9
Supported graphics resolutions1920 x 1080 (HD 1080)
Motion interpolation technologyPPI (Picture Performance Index) 400
Dynamic contrast ratio marketing nameMega Contrast
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Channels quantity- channels
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Video appsAmazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Smart modesGame, Movie, Sports
Lifestyle appsGoogle Apps
Operating system version11
Operating system installedAndroid
Hybrid Broadcast Broadband TV (HbbTV) version1.5
Audio decodersDolby Digital, Dolby Digital Plus
RMS rated power16 W
Number of speakers2
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version5.0
Bluetooth profilesA2DP, HID
Product colorBlack
Mercury content0 mg
Panel mounting interface100 x 100 mm
Processor cores4
Audio formats supportedWMA, MP3
Image formats supportedBMP, JPG, PNG
Video formats supportedAVI, WMV, MP4, MPG, TS, MKV, OGM
Picture processing technologyTCL Pure Image Ultra
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
HDMI version1.4
RF connector typeF, IEC
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Programming period8 day(s)
Number of OSD languages39
Firmware upgradeable viaNetwork, USB
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (max)75 W
Power consumption (standby)0.32 W
Cables includedAC
Remote control typeRC802NU1
Package typeBox
Package depth130 mm
Package width1046 mm
Package height640 mm
Package volume87027.2 cm³
Package weight8680 g
Truck type87 cbm
Pallet width800 mm
Pallet weight116660 g
Pallet net height1420 mm
Pallet net length1200 mm
Quantity per truck396 pc(s)
Quantity per pallet12 pc(s)
Quantity per pallet layer6 pc(s)
Number of layers per pallet2 pc(s)
Number of pallets per truck33 pc(s)
Quantity per master (outer) case1 pc(s)
Master (outer) case GTIN (EAN/UPC)5901292517144
Maximum number of stacking cartons4 pc(s)
Repairability index6.3
Battery typeAAA
Battery weight15 g
Doesn't containMercury
Country of originPoland
Battery technologyAlkaline
CertificationCE
Weight and Dimensions IconWeight and Dimensions
Stand width770 mm
Depth (with stand)186 mm
Width (with stand)905 mm
Height (with stand)575 mm
Weight (with stand)6420 g
Depth (without stand)75 mm
Height (without stand)524 mm
Weight (without stand)6360 g
