TCL 40S5200 User Manual

EN
9
English
Chapter 3 - Basic TV operations
Accessing channels
Using the numeric buttons
: press the corresponding
numeric buttons on the remote control to access the
channels.
Using the P / buttons
: press the
P /
buttons
on the remote control to scroll through the channels.
Using the LIST button
: press the
LIST
button on the
remote control to display the channel list and press
▲/▼/◄/►
and
OK
to select channels.
Watching connected devices
Press on the remote control to display the source
list. Press
▲/▼
to select TV or other input sources
and press
OK
to conrm.
You can also press on the remote control to
display the homepage, press ▲/▼/◄/► to move the
cursor to the area on the right top of the screen,
and press
OK
to enter. Then press ▲/▼ and
OK
to
select the input source.
Adjusting volume
Volume control
: press the
/
buttons on the
remote control to increase or decrease the volume.
Sound mute
: press the button to temporarily mute
the sound. Press this button again or the button
to restore the sound.
Accessing Android TV homepage
Allows you to enjoy Internet Applications (Apps) and
specially adapted Internet websites, and perform
system settings for your TV. You can make controlling
with the TV remote control.
WARNING:
• Congure the network settings before using Smart
TV applications.
• Slow responses and/or interruptions may occur,
depending on your network conditions.
• If you experience a problem using an application,
please contact the content provider.
• According to circumstances of the content provider,
an application’s updates or the application itself may
be discontinued.
• Depending on your country's regulations, some
applications may have limited service or not be
supported.
• Changes in application content may be made
without prior notice by the service provider.
1.
Press on the remote control to display the
Android TV homepage.
2.
Press
▲/▼/◄/►
and
OK
to enter the desired
Apps, functions or settings.
3.
Press to return to the homepage.
Note: Since the connection with Internet takes
time, it’s recommended that you wait a few
minutes to use the Smart TV feature after
activation of TV from standby.
Using TV settings menu
Allows you to adjust TV settings, such as picture and
sound.
1.
Press on the remote control to display the TV
settings menu.
2.
Press
▲/▼
to select the desired item, then press
OK/►
to enter the corresponding submenu.
3.
In submenus, press
▲/▼
to select menu options,
then press
OK/►
to enter the option list, the
adjustment interface, or the corresponding
submenu.
4.
Press to return to the previous menu.
5.
Press
EXIT
or to close the menu.
Notes:
-
You can also press on the remote control,
select TV settings (if available) and press OK to
enter the TV settings menu. Some options may
not be available for certain signal sources.
-
Setting LED motion clear on will make fast
moving images clearer by controlling the LED
backlight, but the picture will be darker and more
ickering than with LED motion clear off.

TCL 40S5200 Specifications

General

Screen shape	Flat
Response time	30 ms
Display diagonal	40 \
Progressive scan	Yes
Anti-glare screen	No
Display brightness	270 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	60 Hz
Peak luminance ratio	76 %
LED backlighting type	Direct-LED
Supported video modes	1080p
Viewable size diagonal	1000 mm
Viewing angle, vertical	- °
Contrast ratio (typical)	-
Display diagonal (metric)	101.6 cm
Screen format adjustments	4:3, 16:9
Supported graphics resolutions	1920 x 1080 (HD 1080)
Motion interpolation technology	PPI (Picture Performance Index) 400
Dynamic contrast ratio marketing name	Mega Contrast
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Channels quantity	- channels
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Video apps	Amazon Prime Video, Apple TV, Disney+, Google TV, HBO, Netflix, Twitch, YouTube
Smart modes	Game, Movie, Sports
Lifestyle apps	Google Apps
Operating system version	11
Operating system installed	Android
Hybrid Broadcast Broadband TV (HbbTV) version	1.5
Audio decoders	Dolby Digital, Dolby Digital Plus
RMS rated power	16 W
Number of speakers	2
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Bluetooth profiles	A2DP, HID
Product color	Black
Mercury content	0 mg
Panel mounting interface	100 x 100 mm
Processor cores	4
Audio formats supported	WMA, MP3
Image formats supported	BMP, JPG, PNG
Video formats supported	AVI, WMV, MP4, MPG, TS, MKV, OGM
Picture processing technology	TCL Pure Image Ultra
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
HDMI version	1.4
RF connector type	F, IEC
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Programming period	8 day(s)
Number of OSD languages	39
Firmware upgradeable via	Network, USB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (max)	75 W
Power consumption (standby)	0.32 W
Cables included	AC
Remote control type	RC802NU1
Package type	Box
Package depth	130 mm
Package width	1046 mm
Package height	640 mm
Package volume	87027.2 cm³
Package weight	8680 g
Truck type	87 cbm
Pallet width	800 mm
Pallet weight	116660 g
Pallet net height	1420 mm
Pallet net length	1200 mm
Quantity per truck	396 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet layer	6 pc(s)
Number of layers per pallet	2 pc(s)
Number of pallets per truck	33 pc(s)
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292517144
Maximum number of stacking cartons	4 pc(s)
Repairability index	6.3
Battery type	AAA
Battery weight	15 g
Doesn't contain	Mercury
Country of origin	Poland
Battery technology	Alkaline
Certification	CE

Weight and Dimensions

Stand width	770 mm
Depth (with stand)	186 mm
Width (with stand)	905 mm
Height (with stand)	575 mm
Weight (with stand)	6420 g
Depth (without stand)	75 mm
Height (without stand)	524 mm
Weight (without stand)	6360 g
