TCL 43C635 User Manual

4
Chapter 2 Connections and Setup
Initial Setup
The rst time you switch the set on, the
Welcome
wizard appears, which guides you through the initial setup process.
Follow the on-screen instructions to nish the initial setup process such as selecting the language, pairing your
remote, connecting to the network, and more. During each step, either make a choice or skip the step. If you skip a
step, you can perform the setup later from the settings menu.
Notes:
- It’s recommended to select
Set up Google TV
and nish its setup to enjoy more features during the initial setup process.
If you have nished basic TV’s setup, you can reaccess Google TV by pressing
on the remote control, selecting
(Settings) > Set up Google TV
and pressing
OK
to conrm.
-
When you pair your remote, keep the remote control and TV within 1 meter, and follow the on-screen guide for
pairing. After nishing pairing the remote, you can use the Google Assistant button. If you skip remote pairing, you
will be prompted to pair the remote with the TV again when you use the Google Assistant button for the rst time.
TV Buttons
-
Power button
If the batteries in your remote control are run down, you can use the button on your TV set.
The model has only one button. It may work just as Standby/Quit standby button, or as a multi-function
controller.
You can turn on the TV by pressing the
button on the TV set.
While the TV is on, press the
button to display the multi-function menu. For more information about how to use
the multi-function menu, please refer to the figure below.
• Press to move the highlight to the next function selection
• Press and hold the button for more than 2 seconds to conrm your selection.
Note:
You can follow the on-screen guide to operate. Figures and illustrations are provided for reference only and may
vary depending on the model.
-
MIC switch
The MIC button is located next to the power button. If you want to use the feature of hands-free TV voice control,
turn on this switch.
CH+ CH- Volume+
Source OKVolume-
Standby
Tips: Short click to change, long click to select.

TCL 43C635 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	43 \
Display brightness	- cd/m²
Display technology	QLED
Native aspect ratio	16:9
Native refresh rate	120 Hz
Contrast ratio (typical)	5000:1
Display diagonal (metric)	108 cm
Motion interpolation technology	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
AMD FreeSync	No
Game features	Auto Low Latency Mode (ALLM), Variable Refresh Rate (VRR)
Processor cores	4
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Product color	Black
Panel mounting interface	200 x 200 mm
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Audio decoders	Dolby Atmos, DTS-HD
RMS rated power	20 W
App distribution platform	Google Play
Operating system installed	Google TV
AC input voltage	110 - 240 V
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
Package depth	133 mm
Package width	1145 mm
Package height	665 mm
Package weight	11000 g
Repairability index	6.8

Weight and Dimensions

Depth (with stand)	250 mm
Width (with stand)	958.1 mm
Height (with stand)	610 mm
Weight (with stand)	8400 g
Depth (without stand)	79.6 mm
Height (without stand)	552 mm
Weight (without stand)	8300 g
