TCL 43C645 Manual

EN
10
English
Chapter 3 - Basic TV operations
Accessing channels
Using the Navigation Direction buttons:
press
/
on the remote control to scroll through the
channels.
Using the OK button
: press the
OK
button to display
the channel list and press
/ / /
and
OK
to
select channels.
Using the CH / buttons:
press the
CH /
buttons on the remote control to scroll through the
channels.
Using the LIST button:
press the
LIST
button on the
remote control to display the channel list and press /
/ / and
OK
to select channels.
Watching connected devices
Press on the remote control to display the source
list. Press / to select TV or other input sources and
press
OK
to conrm.
Adjusting volume
Volume control
: press the
VOL /
buttons on the
remote control to increase or decrease the volume.
Sound mute
: press the button to temporarily mute
the sound. Press this button again or the
VOL
button to restore the sound.
Accessing Smart TV homepage
Allows you to enjoy Internet Applications (Apps) and
specially adapted Internet websites, and perform
system settings for your TV. You can make controlling
with the TV remote control.
WARNING:
• Congure the network settings before using Smart
TV applications.
• Slow responses and/or interruptions may occur,
depending on your network conditions.
• If you experience a problem using an application,
please contact the content provider.
• According to circumstances of the content provider,
an application’s updates or the application itself may
be discontinued.
• Depending on your country's regulations, some
applications may have limited service or not be
supported.
• Changes in application content may be made
without prior notice by the service provider.
1.
Press on the remote control to display the Smart
TV homepage.
2.
Press
/ / /
and
OK
to enter the desired
Apps, functions or settings.
3.
Press to return to the homepage.
Note: Since the connection with Internet takes
time, it’s recommended that you wait a few
minutes to use the Smart TV feature after
activation of TV from standby.
Using Settings menu
Allows you to adjust TV settings, such as picture and
sound.
1.
Press on the remote control to display the
dashboard menu.
2.
Select
Settings
and press
OK
to enter the settings
menu.
3.
In submenus, press
/
to select menu options,
then press
OK
/
to enter the option list, or the
corresponding submenu, or press
OK
to toggle on
or o󰀨, or press
/
to adjust the setting.
4.
Press to return to the previous menu.

TCL 43C645 Specifications

General

DVI port	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio Return Channel (ARC)	Yes
VGA (D-Sub) ports quantity	0
Common interface Plus (CI+) version	1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Pallet width	1200 mm
Pallet height	1470 mm
Pallet weight	137540 g
Pallet net length	800 mm
Quantity per pallet	12 pc(s)
Master (outer) case width	1136 mm
Quantity per pallet layer	6 pc(s)
Master (outer) case height	665 mm
Master (outer) case length	130 mm
Master (outer) case weight	10420 g
Number of layers per pallet	2 pc(s)
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292519742
Maximum number of stacking cartons	4 pc(s)
Video apps	Amazon Prime Video, Apple TV, Disney+, HBO, Netflix, Twitch, YouTube
Operating system version	11.0
Operating system installed	Google TV
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Package depth	123 mm
Package weight	Weight of the packaged product in gram.
Programming period	8 day(s)
Browser supported	-
Processor cores	4
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technology	TCL AiPQ 3.0 Engine
RMS rated power	20 W
Response time	15 ms
Display diagonal	43 \
Display brightness	300 cd/m²
Display technology	QLED
Native refresh rate	60 Hz
LED backlighting type	Direct-LED
Display diagonal (metric)	108 cm
Motion interpolation technology	PPI (Picture Performance Index) 3100
Dynamic contrast ratio marketing name	Mega Contrast
Product color	Black
Panel mounting interface	200 x 200 mm
Battery weight	15 g
Warranty period	2 year(s)
Country of origin	Poland
Battery technology	Alkaline

Weight and Dimensions

Depth (with stand)	252 mm
Height (with stand)	610 mm
Weight (with stand)	7840 g
Depth (without stand)	81 mm
Width (without stand)	959 mm
Height (without stand)	565 mm
Weight (without stand)	7740 g
