TCL 43C645 User Manual

14
- Before using the feature of network wake up, make
sure
Quick start
is set to on.
Using the Hands-free TV Voice Control
(* not available for some models)
Note:
This feature is only available in Google TV mode.
Before using the hands-free TV voice control, connect the
TV to the network and make sure it can access the Goo-
gle website rst. Then follow the steps below to access.
1.
Turn the built-in MIC switch (next to the power
button) to on before using this function.
2.
In Google TV mode, press the Google Assistant
button on your remote.
3.
Select “Yes, I'm in”.
4.
Say “Hey Google” to activate it.
Notes:
-
The availability of hands-free TV voice control
depends on your region/country/language and your
model. For details, please refer to your local dealer.
-
A quiet surrounding is required for better function
when using it. The recommended using distance is
within 2 meters in front of TV set.
-
Turn the built-in MIC switch to o if you are not going
to use it.
-
Standby power consumption will increase because
the built-in MIC is always listening when the Google
Assistant or voice control with the built-in MIC is
enabled.
Network Wake Up
Note:
This feature is only available in Google TV mode.
This function allows you to turn on your TV from standby
mode via a network. To use this function, please make
sure:
1.
Your TV is connected to an effective wireless home
network.
2.
The desired controller, such as a smartphone, is
connected to the same network as your TV.
3.
An app which supports network waking up function,
such as YouTube, has been installed into the
controller.
4. Network Standby
is set to on in the
Network &
Internet
menu. In Google TV mode, press on the
remote control, select
(Settings) > Network &
Internet > Network Standby
, and press
OK
to turn
it on.
When the TV is in networked standby mode, you can
use the app to wake up the TV remotely.
Notes:
- This feature is disabled if you press and hold the
button on the remote control and conrm to shut the
TV down.
Chapter 5 Google TV

TCL 43C645 Specifications

General

DVI port	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio Return Channel (ARC)	Yes
VGA (D-Sub) ports quantity	0
Common interface Plus (CI+) version	1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Pallet width	1200 mm
Pallet height	1470 mm
Pallet weight	137540 g
Pallet net length	800 mm
Quantity per pallet	12 pc(s)
Master (outer) case width	1136 mm
Quantity per pallet layer	6 pc(s)
Master (outer) case height	665 mm
Master (outer) case length	130 mm
Master (outer) case weight	10420 g
Number of layers per pallet	2 pc(s)
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5901292519742
Maximum number of stacking cartons	4 pc(s)
Video apps	Amazon Prime Video, Apple TV, Disney+, HBO, Netflix, Twitch, YouTube
Operating system version	11.0
Operating system installed	Google TV
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Package depth	123 mm
Package weight	Weight of the packaged product in gram.
Programming period	8 day(s)
Browser supported	-
Processor cores	4
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Picture processing technology	TCL AiPQ 3.0 Engine
RMS rated power	20 W
Response time	15 ms
Display diagonal	43 \
Display brightness	300 cd/m²
Display technology	QLED
Native refresh rate	60 Hz
LED backlighting type	Direct-LED
Display diagonal (metric)	108 cm
Motion interpolation technology	PPI (Picture Performance Index) 3100
Dynamic contrast ratio marketing name	Mega Contrast
Product color	Black
Panel mounting interface	200 x 200 mm
Battery weight	15 g
Warranty period	2 year(s)
Country of origin	Poland
Battery technology	Alkaline

Weight and Dimensions

Depth (with stand)	252 mm
Height (with stand)	610 mm
Weight (with stand)	7840 g
Depth (without stand)	81 mm
Width (without stand)	959 mm
Height (without stand)	565 mm
Weight (without stand)	7740 g
