Step 4 Get to know your TV
F
Internet router or switch.
ETHERNET
Connect an Ethernet cable to your home
TV FRONT
TV BACK
USB PORT
Connect a USB device to access photos,
music and movies.
HDMI ARC PORT Connect HDMI ARC
(audio return channel) capable audio devices like
sound bars or AV receivers.
H
4 HDMI PORTS
Highest quality audio/video connection.
Connect cable box, Blu-ray player, gaming console,
or other devices to your TV using HDMI cables.
G
RESET BUTTON Press once to restart your TV.
Press and hold for factory reset, and careful, you will
lose all your settings!
D
E
ANTENNA/CABLE IN Connect an outdoor VHF/UHF
antenna or Cable TV feed.
OPTICAL (DIGITAL AUDIO OUT) Connect an optical
cable to an external digital audio system.
Use the supplied adapter to connect to older devices
that use analog audio/video outputs. The supplied
adapter connects to the RCA cable (video - yellow
and audio - white and red) that you normally use
to connect to that device.
AV IN adapter AV Input (analog audio/video)
I
J
HEADPHONE OUT
Connect headphones or other
external speakers.
K
IR RECEIVER
Receives signal from the
TV remote.
STATUS LIGHT
Glows when the TV is in
standby, flashes when the TV is busy,
flashes once with each button pressof the
remote control.
A
POWER PORT Connect your
C
TV to the power source with the included
power cable.
POWER and OPTIONS BUTTON
B
Found on the corner of the TV back
for
easy use.
C
E
D
G
F
H
I
J
K
A
B
RESET
CABLE/ANT
AUDIO OUT
AV IN
ARC
