II. Press”Pass” to continue;
 GPS
I. It will run GPS and search for satellite, and then it will display info such as “PRN”, “SUR”,
etc. on the screen if it functions well;
II. Press”Pass” to continue;
 NETWORK
I. Insert SIM card and follow the instruction if it functions well.
II. Press”Pass” to continue;
 Calling
I. It will automatically call the emergency call if it functions well.
II. Press “Pass” to continue;
 BATTERY CTRL
I. You will see the battery status information.
II. Press ”Exit” to continue;
 Factory Reset
It will do the factory reset automatically if you press the item.
 EXIT
I. End the TEST and go back the calculator screen
3 Battery
3.1 Battery information
1) Battery picture
