TCL Air Conditioner Service Manual
Part List
Indoor Unit- KFTHP-18
No.
Part No.
Part Name
Q’ty
Remark
1
1080030001
Installation Plate
1
2
1213090101
Base
1
3
1070020014
Cross Fan
1
4
1070100010
Bearing Mount
1
5
1170030075
Indoor Motor
1
6
1073090120
Indoor Motor Clamp
1
7
1170020011
Vane Motor
2
8
1083090108
Clip Base
1
9
1110050896
Evaporator
1
10
1213090102
Water Drainage Assembly
1
11
1073090105
Vertical Vane Supporter
1
12
1073090106
Vertical Vane A
14
1073090107
Vertical Vane B
2
13
1070110011
Drainage Hose
1
14
1170230001
Indoor Sensor Assembly
1
15
1173090107
Transformer
1
16
1070500692
Front Panel
1
17
1070500502
Display PCB Cover
1
18
1091990054
Heater
1
19
1073090126
Display PCB Box
1
20
1090500501
Display PCB
1
21
1073090108
Vane A
1
1073090125
Vane B
1
22
1073090112
Left Air Filter
1
1073090113
Right Air Filter
1
23
1073090111
Screw Cover
3
24
1070500312
Face Frame
1
25
1073090114
Electrical Box Cover
1
26
1090700209
Main PCB
1
27
1073090121
Electrical Box
1
28
1070500008
Breakwater
1
29
1090050318
Remote Controller
1
Not shown in
Explosion view
30
1070060003
Remote Controller Supporter
1
31
1190060003
Indoor Carton
1
32
1190060019
Left Foaming
1
33
1190060020
Right Foaming
1
34
1190060002
Middle Pasteboard Supporter
1
35
1190060021
Middle Foaming Supporter
1
