TCL Air Conditioner Service Manual
Part List
Indoor Unit- KFTHP-24
No. Part No. Part Name Q’ty Remark
1
1080030017
Installation Plate
1
2
1070850102
Base
1
3
1070020021
Cross Fan
1
4
1070100014
Bearing Mount
1
5
1170030076
Indoor Motor
1
6
1070850133
Indoor Motor Clamp
1
7
1170020023
Vane Motor
2
8
1070850140
Clip Base
1
9
1110050894
Evaporator
1
10
1210850106
Water Drainage Assembly
1
11
1070850114
Left Vertical Vane Supporter
1
1070850116
Middle Vertical Vane Supporter
1
1070850119
Right Vertical Vane Supporter
1
12
1070850121
Large Vertical Vane
16
1070850122
Middle Vertical Vane
2
1070850123
Small Vertical Vane
2
13
1070110012
Drainage Hose
1
14
1170230001
Indoor Sensor Assembly
1
15
1173090107
Transformer
1
16
1070850257
Front Panel
1
17
1070850148
Display PCB Cover
1
18
1091990055
Heater
1
19
1070850145
Display PCB Box
1
20
1090500501
Display PCB
1
21
1070850107 Up Vane
1
1070850108 Down Vane
1
22
1070850131
Air Filter
2
23
1070850130
Screw Cover
3
24
1070850126
Face Frame
1
25
1070850219
Electrical Box Cover
1
26
1090850117
Main PCB
1
27
1070850132
Indoor Motor Base
1
28
1070850133
Indoor Motor Cover
1
29
1070850218
Electrical Box
1
30
1070850103
In And Out Pipe Fixer
1
31
1070850135
Breakwater
1
32
1090050318 Remote Controller
1 Not shown in
Explosion view
33
1070060003 Remote Controller Supporter
1
34
1190040008 Indoor Carton
1
35
1190070037 Base Foaming
1
36
1190070038 Upper Foaming
1
