TCL Air Conditioner Service Manual
Part List
Outdoor Unit- KFTHP-12
No. Part No. Part Name
Q’ty
Remark
1 1400250857
Grille
1
2 1080050011
Top Cover
1
3
1110060867
Condenser
1
4 1080050001
Left Grille Supporter
1
5 1080050007
Left Grille
1
6
1080050009
Front Plate
1
7 1080320112
Fan Guard
1
8 1210250121
Base
1
9
1100060092
Compressor And It Accessories
1
10
1120500226
4-way Valve
1
11
1120250561
4-way Valve Assembly
1
12
1080050003
Valve Supporter
1
13
1120120021
Two-way Valve
1
14
1120130036
Three-way Valve
1
15
1081990107
Electrical Box Cover
1
16 1080050002
Right Plate
1
17
1070040001
Cable ClampФ6
1
1070040003
Cable ClampФ8
1
1070040008
Cable ClampФ10
1
18
1171990049
Terminal
1
19
1170100004
Compressor Capacitor
1
20
1080010006
Capacitor Strip
1
21
1170100032
Fan Motor Capacitor
1
22
1080020001
Electrical Parts Box
1
23 1120350781
Capillary Assembly
1
24
1080170001
Partition plate
1
25 1070030016
Propeller Fan
1
26 1170040064
Outdoor Motor
1
27 1080050004
Outdoor Motor Supporter
1
28
1190070020 Base Carton 1
Not shown in the
Explosion view.
29
1190070002 Cabinet Carton 1
30
1190070022 Base Foaming 1
31
1190070021 Cover Forming 1
２５
