Part List
Outdoor Unit- KFTHP-18
No. Part No. Part Name Q’ty Remark
1
1071990041
Grille
1
2
1081990038
Top Cover
1
3
1110061027
Condenser
1
4
1081990040
Left Grille Supporter
1
5
1081990045
Left Grille
1
6
1081990047
Front Plate
1
7
1081990048
Fan Guard
1
8
1081990052
Base
1
9
1100060093
Compressor And It Accessories
1
10
1120500226
4-way Valve
1
11
1120500853
4-way Valve Assembly
1
12
1081990041
Valve Supporter
1
13
1120120021
Two-way Valve
1
14
1120130032
Three-way Valve
1
15
1081990107
Electrical Box Cover
1
16
1081990039
Right Plate
1
17
1074060118
Cable Clamp
1
18
1171990049
Terminal
1
19
1170100026
Compressor Capacitor
1
20
1080010006
Capacitor Strip
1
21
1170100030
Fan Motor Capacitor
1
22
1081990049
Electrical Parts Box
1
23
1120500852
Capillary Assembly
1
24
1174561801
AC Contactor
1
25
1141990004
Sound Insulation
1
26
1070030025
Propeller Fan
1
27
1170040112
Outdoor Motor
1
28 1081990042
Outdoor Motor Supporter
1
29 1190060191 Base Carton 1
Not shown in the
Explosion view.
30 1190500707 Cabinet Carton 1
31 1190060190 Base Foaming 1
32 1190070052 Cover Forming 1
