TCL MT5655-LA User Manual

Factory Test & Alignment Specification For MT56 Series (V1.0)
4
Input
&
Output
Audio Out
RCA*2
USB
(Video, audio and picture)
USB2.0*2
MHL
Shares with HDMI 1
PCMCIA
1
SPDIF output
RCA*1
NETWORK
RJ45 Socket
Functions
Internet

WIFI

Others
Serial connector
Multiplexing VGA
IC Details
&
Position
Main program
UF01
(Support online upgrade)
Mboot
UF01
(Support online upgrade)
EEPROM
U702
Note:
 The software boot for U702 can be programed by Flash Tool.exe.
 Every set has its unique HDCP key which is purchased from suppliers or HDCP
certification authority. Please check HDCP function in the process of production.
 Once in a while, the software of main board may be upgraded. Please pay attention to
use the latest software before production.

TCL MT5655-LA Specifications

General

Brand	TCL
Model	MT5655-LA
Category	TV
Language	English
