Warning: This product should only be mounted by a professional installer.
Warning: Never install or mount this product to the ceiling with the screen side facing down.
Installing or mounting this product to the ceiling or the underside of a structure or surface is
hazardous and may result in personal injury and/or property damage.
Optional - To mount on a wall
(wall mount not included)
Preparation must be done before mounting your TV on a wall.
Note: Do not place your TV in a location exposed to direct sunlight, heat, fire, or moisture.
To mount on a wall
The VESA number is the horizontal and vertical measurement of the mounting holes. For
example, 200X200 refers to the fact that the mounting measurements are 200mm horizontally
and 200mm vertically.
Follow the instructions that come with the wall mount.
Your wall mount must be able to bear a minimum of five times the TV’s net weight to avoid
causing damage.
55” Models Purchase a VESA 300x300, 4 M6x12mm screws
50” Models Purchase a VESA 300x300, 4 M6x12mm screws
To mount your TV to the wall, purchase a VESA wall mount
If you are mounting your TV to the wall, don’t attach the stands.
65” Models Purchase a VESA 400x300, 4 M6x12mm screws
75” Models Purchase a VESA 400x300, 4 M6x16mm screws
6
1 2
Place your TV on a soft, cushioned surface. Screw the VESA
bracket tightly onto the back cover with 4 VESA screws
purchased with the wall mount separately.
Follow the instructions that come with the wall mount to
hang the TV on the wall.
Exposure will damage the TV.
