> 2"

24.8"

Wall mount your Sound Bar

Required tools:

Place the supplied wall mount template on the

wall. Make sure the wall mount template is at

least 2 inches below the center of the TV.

Use the tape to stick the wall mount template

firmly on the wall.

Mark on the wall using each marking on the

template through the mounting holes.

Take away the wall mount template.

Drill a screw hole at each marking on the wall.

Use a level to make sure the wall mount template

is positioned accurately

Place your Sound Bar

and Subwoofer

Sound Bar on the table

Top View

The ideal place to position the Sound Bar is

centered underneath your TV.

Note: Do not place your sound bar in a location

exposed to direct sunlight, heat, fire, or moisture.

Note: It’s recommended to keep the distance

within 9.8 feet between the Surround Sound

Speakers and the sound bar.

Subwoofer beside

Surround speaker on the left

Surround speaker on the right

Questions and Answers:

Need help?

Do you have a question about the TCL Q6510 and is the answer not in the manual?

TCL Q6510 Specifications

General

Equalizer	Yes
Audio decoders	DTS Virtual:X, Dolby Audio, Dolby Digital, Dolby Digital Plus
Equalizer modes	Game, Movie, Music, Sport, Standard, Voice
RMS rated power	430 W
Audio output channels	5.1 channels
Number of speakers	8
Product color	Black
Package type	Box
Package depth	431.8 mm
Package width	975.36 mm
Package height	271.78 mm
Package weight	11067.65 g
Cables included	AC, HDMI
Number of products included	1 pc(s)
Wi-Fi	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Subwoofer connectivity	Wireless
Woofer diameter (subwoofer)	6.5 \
