TCL TAC-07CS/K

TCL Air Conditioner Service Manual
30
Parts List
Indoor Unit- TAC-12CS/K
No. Part No. Part Name Q’ty Remark
1 1080030008 Installation Plate 1
2 1210320107 Base 1
3 1070020016 Cross Fan 1
4 1070100010 Bearing Mount 1
5 1210320601 Evaporator 1
6 1210320108 Water Drainage Assembly 1
7 1070320105 Vertical Vane Assembly 2
8 1070320107 Face Frame 1
9 1070320112 Screw Cover 2
10 1090320102 Display PCB 1
11 1070320115 Display PCB Box 1
12 1070320110 Display PCB Cover 1
13 1070320109 Air Filter 2
14 1070321501 Front Panel 1
15 1170120047 Power Supply Cord 1
16 1070320104 Vane 1
17 1070110008 Drainage Hose 1
18 1070040004 Cable Clamp 1
19 1170200039 Terminal 1
20 1070250109 Terminal Fixing Board 1
21 1090320702 Main PCB 1
22 1070320113 Electrical Box 1
23 1170020011 Vane Motor 1
24 1073030201 Sensor Holder 1
25 1170030047 Indoor Motor 1
26 1070320111 Indoor Motor Cover 1
27 1170240001 Transformer 1
28 1170230001 Pipe Temp. Sensor & Room
Temp. Sensor Assembly
1
29 1070320101 In And Out Pipe Fixer 1
30 1090010071 Remote Controller 1
31 1073030303 Remote Controller Supporter 1
31 1190060010 Indoor Carton 1
32 1190060008 Left Foaming 1
33 1190060009 Right Foaming 1
Not shown in Explosion
view
