TCL Air Conditioner Service Manual
37
Part List
Outdoor Unit- TAC-07CHS/K, TAC-09CHS/K
No. Part No. Part Name Q’ty Remark
1 1083510901 Grille 1
2 1080050016 Top Cover 1
3 1210250304 Condenser 1
4 1080050015 Outdoor Motor Supporter 1
5 1170040062 Outdoor Motor 1
6 1070030006 Propeller Fan 1
7 1080050012 Left Plate 1
8 1080050018 Front Plate 1
9 1080050019 Fan Guard 1
10 1100170018 Compressor and its Accessories 1
11 1123530404 Suction Pipe 1
12 1123530407 Three-way Valve Connecting Pipe 1
13 1123530405 Discharge Pipe 1
14 1120110002 4-way Valve Assembly 1
15 1123530406 Condenser Connecting Pipe 1
16 1213530414 Base 1
17 1080050013 Right Plate 1
18 1120120008 Two-way Valve 1
19 1080050014 Valve Supporter 1
20 1120130011 Three-way Valve 1
21 1073521301 Electrical Box Cover 1
22 1070040001 Cable Clamp 1
23 1070040002 Cable Clamp 1
24 1170200020 Terminal 1
25 1170100031 Fan Motor Capacitor 1
26 1170100014 Compressor Capacitor 1
1080010002 Capacitor Strip
28 1080020001 Electrical Parts Box 1
29 1210250150 Capillary Assembly 1
30 1190070014 Base Carton 1
31 1190250201 Cabinet Carton 1
32 1190070016 Base Foaming 1
33 1190070015 Cover Forming 1
Not shown in the Explosion
view.
