TCL TAC-07CS/K

TCL Air Conditioner Service Manual
38
Outdoor Unit- TAC-12CS/K
No. Part No. Part Name Q’ty Remark
1 1080050025 Grille 1
Optional
2 1080320105 Top Cover 1
3 1210320106 Condenser 1
4 1080050004 Outdoor Motor Supporter 1
5 1170040058 Outdoor Motor 1
6 1070030016 Propeller Fan 1
7 1080050001 Left Grille Supporter 1
8 1080050007 Left Grille 1
9 1080320113 Front Plate 1
9 1080320112 Fan Guard 1
10 1210320705 Capillary Assembly 1
11 1100170004 Compressor and its Accessories 1
12 1120320707 Discharge Pipe 1
13 1120320708 Suction Pipe 1
14 1210320103 Base 1
15 1120120016 Two-way Valve 1
16 1080050003 Valve Supporter 1
17 1120130021 Three-way Valve 1
18 1080050002 Right Plate 1
19 1073551103 Electrical Box Cover 1
20 1080010006 Capacitor Strip 1
21 1070040003 Cable Clamp(φ8) 1
22 1170200019 Terminal 1
23 1170100003 Compressor Capacitor 1
24 1170100010 Fan Motor Capacitor 1
25 1080020001 Electrical Parts Box 1
26 1190070014 Base Carton 1
27 1190070008 Cabinet Carton 1
28 1190070016 Base Foaming 1
29 1190070015 Cover Forming 1
Not shown in the Explosion
view.
