TCL Air Conditioner Service Manual
39
Outdoor Unit- TAC-12CHS/K
No. Part No. Part Name Q’ty Remark
1 1080050025 Grille 1
Optional
2 1080320105 Top Cover 1
3 1210350201 Condenser 1
4 1080050004 Outdoor Motor Supporter 1
5 1170040058 Outdoor Motor 1
6 1070030016 Propeller Fan 1
7 1080050001 Left Grille Supporter 1
8 1080050007 Left Grille 1
9 1080320113 Front Plate 1
10 1080320112 Fan Guard 1
11 1100170004 Compressor And It Accessories 1
12 1120320102 Suction Pipe 1
13 1120320103 Three-way Valve connecting Pipe 1
14 1120320115 Discharge Pipe 1
15 1120110002 4-way Vane Assembly 1
16 1120320104 Condenser connecting Pipe 1
17 1210320103 Base 1
18 1080050002 Right Plate 1
19 1120120016 Two-way Valve 1
20 1080050003 Valve Supporter 1
21 1120130021 Three-way Valve 1
22 11073551103 Electrical Box Cover 1
23 1070040001 Cable Clamp(φ6) 1
24 1070040002 Cable Clamp(φ7) 1
25 1170200020 Terminal 1
26 1170100032 Fan Motor Capacitor
27 1170100003 Compressor Capacitor 1
28 1080010006 Capacitor Strip
29 1080020001 Electrical Parts Box
30 1210320115 Capillary Assembly
31 1190070017 Base Carton 1
32 1190500302 Cabinet Carton 1
33 1190070019 Base Foaming 1
34 1190070018 Cover Forming 1
Not shown in the Explosion
view.
